XCMG XS223JE single steel wheel vibratory roller high efficiency energy saving roller

Categories	Trucks
Brand	Yitongda China Used Cars for Sale
Model	XCMG XS223JE
Update Time	Nov 18,2024

Contact Now

Favorites

Detail Information

Product Description

Performance characteristics：

1. The use of Shanghai Diesel National III high-pressure common rail electronically controlled low-speed diesel engine achieves the best fuel consumption working area, reducing the overall fuel consumption by 10%;

2. The low-speed diesel engine reduces noise emissions and enhances the sealing of the whole machine, reducing the noise of the whole machine by 2 decibels;

3. Optimize the matching of the transmission system to achieve the best compaction operation speed, and improve the operation efficiency by 8%;

4. The speed of clutch engagement is improved from the original manual control to system intelligent control, which solves the impact of human factors on the system and greatly improves the reliability of the clutch system;

5. The front hood has a large opening angle, and the electric lifting device can safely stop the hood at any position during the lifting process, and the system components are easy to maintain;

Specifications

Type		X3223JE
Working mass (kg)		22000
Drive wheel distribution mass (kg)		11000
Vibrating wheel distribution mass (kg)		11000
Static linear load (N/cm)		516
Vibration frequency (Hz)		28/33
Theoretical amplitude (mm)		1.86/0.93
Exciting force (kN)		374/290
速度范围（km/h）	I	2.69
	II	5.25
	III	11.12
	I	2.66
	Ⅱ	5.27
Wheelbase(mm)		3230
Compacting width (mm)		2130
Theoretical climbing ability (%)		30
Minimum turning radius (mm)		6500
Vibrating wheel diameter (mm)		1600
Minimum ground clearance (mm)		440
Engine rated power (kW)		140
Overall dimensions (length x width x height) (mm)		6320×2390×3200
